1030nm Online Isolator(50mW)
Low Insertion Loss
High Return Loss
High Extinction Ratio
High lsolatior
High Stability and Reliability
Applications:
Communication Systems
Test Instrument
Fiber Sensors
Product Development
| Quantity: | |
|---|---|
| PDF Export | |
Product Description
| Parameter Spec | Unit | |||
| Grade | Single | Dual | / | |
| Center Wavelength | 1030 | nm | ||
| Operating Wavelength Range | ±5 | nm | ||
| Typ.Peak Isolation @23℃ | 23 | 38 | dB | |
| Min.Isolation @23℃ | 20 | 35 | dB | |
| Typica Insertloss @23℃ | 3 | 6 | dB | |
| Max.Insertion Loss@23℃ | 3.2 | 6.5 | dB | |
| Min.Return Loss(Input &Output) | 50/50 | dB | ||
| Min.Extinction Ratio @23℃ | BothAxis Working | 20 | dB | |
| Fast Axis Block | 22 | dB | ||
| Max.Polarization Dependent Loss @23℃(Single Mode Fiber Type) | 0.15 | dB | ||
| Max.Optical Power(CW) | 50 | mW | ||
| Max.Tensile Load | 5 | N | ||
| Fiber Type | PM Panda fiber orSingle-mode fiber | / | ||
| Operating temperature | -5~+50 | ℃ | ||
| Storage temperature | -40~+85 | ℃ | ||
Key Features
Low Insertion Loss
The 030nm Online Isolator provides a typical insertion loss of 3 dB at 23°C, making it ideal for systems where maintaining signal strength is crucial. The maximum insertion loss is 3.2 dB, ensuring minimal signal attenuation.High Return Loss
With a minimum return loss of 50 dB, the isolator minimizes signal reflection, which is essential for maintaining clear, high-quality signals throughout the system.High Extinction Ratio
Featuring a typical extinction ratio of 30 dB at 23°C, this isolator ensures that unwanted light is effectively blocked, ensuring precise polarization control for demanding optical systems.High Isolation
The device provides a typical peak isolation of 23 dB for single-axis and 38 dB for dual-axis configurations. High isolation is vital for preventing signal interference and ensuring optimal system performance.
Applications
1. Communication Systems
Ideal for fiber optic communication networks, the isolator ensures reliable signal transmission and reduces signal degradation in long-distance optical systems.
2. Test Instruments
Used in test instruments, it guarantees stable and accurate measurements by preventing unwanted reflections and interference during optical system diagnostics.
3. Fiber Sensors
The isolator enhances fiber sensor performance by maintaining signal integrity and minimizing distortion, critical for precise measurements in environmental and industrial applications.
4. Product Development
The 030nm Online Isolator is also valuable in product development, where stable polarization and minimal loss are essential for creating new optical devices and systems.
FAQ
1. What is the maximum optical power handling capacity?
The 030nm Online Isolator can handle up to 50 mW (CW), making it suitable for high-power optical applications.
2. Can the isolator be used in extreme temperatures?
Yes, it operates within a temperature range of -5°C to +50°C and can be stored at temperatures ranging from -40°C to +85°C.
3. How does high isolation benefit the system?
High isolation ensures that unwanted signals are prevented from interfering with the input and output, maintaining signal clarity and system integrity.
4. What types of fibers are compatible with this isolator?
The isolator works with both PM Panda fiber and single-mode fiber, offering versatility for various optical applications.
