Product Description
Parameter | Spec | Unit | ||||||||
Center Wavelength | 2000 | 1150 | 1130 | 1064 | 980 | 850 | 780 | nm | ||
Operating Wavelength Range | ±50 | ±50 | ±50 | ±30 | ±10 | ±10 | ±10 | nm | ||
Typical Insert loss@23℃ | 0.8 | 0.3 | 0.3 | 0.5 | 0.6 | 0.6 | 0.6 | dB | ||
Max.Insertion Loss @23℃ | 1.0 | 0.5 | 0.5 | 0.7 | 0.8 | 0.8 | 0.8 | dB | ||
Min.Return Loss | 50 | 50 | 50 | 50 | 50 | 50 | 50 | dB | ||
Typical Extinction Ratio @23℃ | 22 | 30 | 30 | 30 | 30 | 28 | 28 | dB | ||
Min.Extinction Ratio @23℃ | 20 | 28 | 28 | 28 | 28 | 25 | 25 | dB | ||
Input&Output Fiber Type | SM→SM or SM→PM | / | ||||||||
Max.Optical Power(CW) | 300 | mW | ||||||||
Max.Tensile Load | 5 | N | ||||||||
Operating temperature | -5~+70 | ℃ | ||||||||
Storage temperature | -40~+85 | ℃ |
The Mini Hybrid Devices are compact, high-performance modules integrating optical and electrical functionalities to enable seamless photonic-electronic convergence in space-constrained applications. Each device combines a high-speed optical transceiver (laser diode/photodetector) with low-power signal processing circuitry (amplifiers, drivers, or controllers), all housed in a hermetically sealed package (≤15mm x 10mm x 5mm). Engineered for high-density integration, they support both analog and digital signal processing, making them ideal for next-generation communication, sensing, and automation systems.
Multi-Domain Integration: Combines optical input/output (via FC/APC or LC connectors) with electrical interfaces (GPIO, I2C, SPI) for real-time control and monitoring.
High-Speed Signal Processing: Supports data rates up to 50 Gbps (digital) or 10 GHz (analog) with ultra-low latency (<1 ns for optical-to-electrical conversion).
Low Power Consumption: Advanced CMOS technology ensures power dissipation ≤1.5 W (active), ≤100 μW (standby), ideal for battery-powered or thermal-constrained systems.
Thermal & EMI Stability: Built-in thermoelectric cooler (TEC) maintains die temperature within ±0.5°C, while a metallic shield reduces electromagnetic interference (EMI) by ≥20 dB.
Flexible Configuration: Customizable for specific protocols (Ethernet, CPRI, Fibre Channel) and wavelengths (850 nm, 1310 nm, 1550 nm).
5G & 6G Networks: Enables compact 前传 /backhaul links in massive MIMO base stations, reducing size and power consumption in remote radio heads (RRHs).
Data Centers: Facilitates high-density optical interconnects in 400G/800G switch fabrics, minimizing latency and cabling complexity in server racks.
Industrial Automation: Integrates optical feedback with electrical control in smart factories, supporting real-time monitoring of robotic arms and conveyor systems.
Medical Devices: Combines optical imaging (e.g., OCT, endoscopy) with low-power signal processing in minimally invasive surgical tools.
Aerospace & Avionics: Reliable performance in airborne systems (e.g., missile guidance, drone communication) with strict SWaP (size, weight, power) constraints.
Q: What is the key advantage of a hybrid device over separate optical and electrical components?A: Integration reduces signal loss, latency, and electromagnetic interference while saving 50%+ space compared to discrete solutions.
Q: Can it operate at cryogenic temperatures for quantum computing?A: Standard models operate from -20°C to 70°C; cryogenic variants (-196°C to 25°C) are available for specialized research applications.
Q: How are optical and electrical signals isolated to prevent crosstalk?A: A dual-layer PCB with ground planes and shielded vias ensures signal isolation ≥30 dB across all frequency bands.
Q: What is the typical bit error rate (BER) for digital models?A: BER ≤1e-12 at 50 Gbps with appropriate signal conditioning, meeting industry standards for data center applications.
Q: Is programming support available for custom signal processing?A: Yes, firmware development kits (FDKs) include drivers for popular OSes (Linux, Windows) and hardware description languages (Verilog).
