TGG In-line Isolator Optical Fiber Online Isolator

Product Features

● Exceptional Isolation Performance: The TGG In-line Isolator provides superior isolation levels, ensuring minimal interference from reflected signals. It effectively protects sensitive components from back-reflection, achieving isolation values of up to 42 dB.

● Enhanced Power Handling: Capable of managing both high average power and peak power, the isolator can handle up to 50 W of average power and 10 kW of peak power, making it ideal for use in high-power laser systems.

● Minimal Polarization Sensitivity: Featuring a polarization-insensitive design, this isolator delivers consistent performance regardless of polarization variations, ensuring stable operation in dynamic environments.

● Broad Wavelength Compatibility: Available for a wide range of wavelengths (850, 980, 1030, 1060, 1080 nm), it is compatible with various fiber types and laser systems, providing flexibility across multiple applications.

● Compact and Reliable Design: Built for durability and reliability, the isolator’s compact form factor allows it to seamlessly integrate into fiber-optic systems without compromising performance, making it suitable for both commercial and industrial use.

● Stable Long-Term Operation: With a high return loss of ≥50 dB and low insertion loss (typically 0.7 dB), this isolator ensures long-term stable operation, helping to reduce system downtime and maintenance costs.

Product Uses

The TGG In-line Isolator is designed for use in a range of optical systems requiring high isolation and low insertion loss. It is ideal for applications such as fiber optic communications, laser systems, and optical fiber amplifiers. This isolator is used in MOPA fiber laser systems, where high stability and protection from feedback are essential. Additionally, it is well-suited for PM optical fiber amplifiers, providing optimal performance in sensitive environments.

Usage Scenarios

● Fiber Optic Communications: Ensures clean, uninterrupted signal transmission by preventing back-reflection.

● MOPA Fiber Lasers: Protects the laser system by isolating the laser source from any back-reflection.

● Optical Fiber Amplifiers: Ideal for high-power amplifier systems, where feedback can severely impact performance.

FAQ

Q1: What is the primary advantage of using TGG technology in this isolator?

A1: TGG technology provides high isolation and minimal polarization-dependent loss, making it ideal for high-power and high-precision applications.

Q2: What is the maximum average power this isolator can handle?

A2: The TGG In-line Isolator can handle average powers from 0.3 W to 50 W, making it suitable for various optical fiber systems.

Q3: What fiber types are compatible with this isolator?

A3: This isolator is compatible with HI1060 and LMA10-30μm fiber types, providing flexibility for different fiber-optic configurations.

Q4: Can this isolator handle high-power laser systems?

A4: Yes, it is designed to handle high-power laser systems, with peak power ratings of up to 10 kW.

Q5: How does this isolator perform in extreme temperatures?

A5: The isolator is designed to operate efficiently in a wide temperature range, from 0°C to +65°C, and can withstand storage temperatures between -20°C and +85°C.
